  • B-800PF

ADD TO COMPARE

B-800SF, 48″ W Ice Storage Bin – Stainless Steel Exterior

  • Dimensions: 48″ W x 32- 1/2 ” D x 46″ H
  • Stores up to 800 lbs of ice
  • AHRI-Rated Storage Capacity: 600 lbs
  • Durable and easy to clean Stainless Steel exterior
  • Polyethylene bin liner for sanitary ice storage
  • Foamed-in-place polyurethane insulation
  • Protected by H-GUARD Plus Antimicrobial Agent
  • For top-mounted ice maker, top kits sold separately (See spec sheet for details)
  • Top-hinged front-opening bin door
  • Sturdy construction capable of supporting stacked ice machine configurations
  • Standard with 6″ Painted Legs
  • Optional: Four, 6″ Stainless Steel Legs – LP-6 LEG
  • 3/4″ FPT drain
  • 210 lbs
  • Two Years: Parts & Labor warranty (Before January 2012 production)
SKU: B-800SF Categories: , ,

LIBRARY

DESCRIPTION

Safely store up to 800 lbs of ice with this B-800SF 48″ ice storage bin! It boasts foamed-in-place polyurethane insulation in all of the bin walls and the bottom of the unit to provide you with maximum ice preservation. The B-800SF features a durable Stainless Steel cabinet with a seamless, easy to clean, polyethylene bin liner. This model comes Standard with 6″ Painted Legs and a Top-hinged front-opening bin door. 3/4″ FPT drain. The unit is AHRI Standard 820, NSF, ISO 9001:14001, Manufactured in the USA and includes a Two Years: Parts & Labor warranty (Before January 2012 production) / Three Years: Parts & Labor warranty (After Janurary 2012 production ).

SPECIFICATIONS

Weight 210 lbs lbs
Dimensions 32- 1/2 " D x 48" W x 46" H in
Height

46″ H

Width

48″ W

Depth

32- 1/2 ” D

Shipping Weight

210 lbs

Certifications:

AHRI Standard 820, NSF, ISO 9001:14001, Manufactured in the USA

Energy Star® Qualified:

No

Utilities:

Plumbing: 3/4″ FPT drain

Ice Storage Capacity:

800 lbs, AHRI-Rated Capacity: 600 lbs

Compatible Icemakers:

KM-340M, KM-515M, KM-600M, KM-650M, F-450M, F-801M, F-1001M, KMD-410M, KMS-822M, FD-650M-C, FD-1001M-C, KM-901M, KM-1340M, KM-1601M, KML-250M, KML-351M, KML-451M, KML-631M, F-1500M, F-2000M, KMD-450M

Size Specs:

Dimensions: 48″ W x 32- 1/2 ” D x 46″ H, Shipping Weight: 210 lbs
